SAM-Approved Business Vendor
The Dell Precision T5820 Workstation is a high-performance solution for professionals working with Adobe After Effects, offering the power and reliability needed for creating complex motion graphics, VFX, and video compositing. Powered by an Intel Xeon W-2145 processor, featuring 8 cores and a base clock speed of 3.7 GHz (boosting up to 4.5 GHz), this workstation ensures smooth, efficient processing for heavy-duty tasks such as animation rendering and applying intricate visual effects. The 64GB of DDR4 RAM provides ample memory for multitasking, allowing users to handle multiple layers, complex compositions, and resource-intensive effects in After Effects without slowdowns.
The NVIDIA GeForce RTX 2080 graphics card offers exceptional GPU acceleration, making real-time previews, 3D rendering, and effects processing faster and more efficient. This is crucial for maintaining workflow speed and ensuring smooth performance while working on high-resolution projects. The storage configuration includes a new 512GB NVMe M.2 drive, providing ultra-fast boot times and quick access to frequently used files and applications, alongside a 2TB SATA HDD for ample space to store large project files, video assets, and rendered outputs.
Additionally, the system comes with a 1 Year – PCSP Advantage Warranty, covering all costs related to replacing any defective components, ensuring peace of mind and long-term reliability. The Dell Precision T5820 Workstation is an excellent choice for professionals using Adobe After Effects, providing the power, storage, and graphics capabilities necessary for high-performance video editing and motion graphics work.
*** Please note: Applications are not included and must be installed by the user. ***
PCSP Standard 1 Year full coverage of parts, labor, and shipping.
Installing this unit at a commercial location?
This unit is eligible for on-site service with PCSP Securit. Click here to learn more
Model
- Brand:
- Dell
- Series:
- Precision
- Model Number:
- T5820
- Form Factor:
- Workstation
- Chassis:
- Dell Precision T5820 Workstation
Quick Info
- Shipping:
- Free Shipping
- Power Supply:
- 950W
- Package Contents:
- WiFi + Bluetooth 4.0 USB Adapter Dongle
Processor
- Heatsinks Installed:
- 1 heatink included
- Maximum CPUs:
- 1
- Processor:
- Intel Xeon W-2145
- Socket:
- LGA2066
- Processors Installed:
- 1 processor installed
- Processor Speed:
- 3.70 GHz
- Processor Max Speed (Turbo Boost):
- 4.50 GHz
- Processor Cores:
- 8 Cores
- Number of Threads:
- 16 Threads
- Hyper Threading:
- Yes
- CPU Cache:
- 11 MB
Graphics
- Graphics Card:
- NVIDIA GeForce RTX 2080
- Graphics Card Memory:
- 8GB
- Graphics Card Memory Type:
- GDDR6
- Graphics Card Clock Speed:
- 1515 MHz - Boost 1710 MHz
- Graphics Card CUDA Cores:
- 2944
- Graphics Card Video Outputs:
- 3x DisplayPort 1.4a, 1x HDMI 2.0, 1x USB-Type-C
Memory
- DIMM Slots:
- 8
- Memory (RAM):
- 64GB
- RAM Type (DDR):
- DDR4
- RAM ECC:
- ECC REG
- RAM Speed (MHz):
- 2666 MHz
Storage
- Drive Bays:
- 4x 3.5"/2.5"
- Storage:
- 1x NEW 512GB NVMe M.2 SSD + 1x 2TB SATA HDD
Optical Drive
- Optical Drive:
- not included
Software
- Operating System:
- Windows 11 Professional
Display
- Monitor:
- not included
Connectivity
- Bluetooth:
- not included
- RJ45:
- 1x 1GbE RJ45 (Integrated)
Front Panel Ports
- Front USB:
- 2x USB 3.1, 2x USB-C 3.1
- Front Audio Ports:
- Headset port
- SD Card Reader / Media Bay:
- not included
Back Panel Ports
- Rear USB:
- 6x USB 3.1
- Rear Audio Ports:
- Microphone /Line-in port, Line-out port
Keyboard & Mouse
- Keyboard:
- not included
- Mouse:
- not included
Dimensions & Weight
- Length:
- 20.41 in.
- Width:
- 6.95 in.
- Height:
- 16.45 in.
- Weight:
- 44.70 LBS.
