Supermicro – 48-Port 1GbE 4-Port 10GbE SFP+ L3 Switch Reverse Airflow – (SSE-G3648BR)

Supermicro – 48-Port 1GbE 4-Port 10GbE SFP+ L3 Switch Reverse Airflow – (SSE-G3648BR)

SKU:
SSE-G3648BR


Request for Quote

(No reviews yet)
Condition:
Refurbished
Brand:
SuperMicro
Series:
SuperSwitch
Model Number:
SSE-G3648BR
Network Interface:
Ethernet (RJ-45) & SFP+
Power Supply:
2x DPS-200PB-184 200W
Rail Kit:
Mounting Flanges Included (Outer rails optional)
Ports:
48x 1Gbps RJ45, 4x 10Gbps SFP+, 1x RJ45 Management
Ears Included:
Yes
Feature Sets:
Layer 2/3 Advanced Enterprise Routing
Adding to cart… The item has been added
Was: $162.49
$124.99
(You save $37.50)
Adding to cart… The item has been added

Description

Supermicro SSE-G3648BR 48-Port 1GbE 4-Port 10GbE SFP+ Switch

Brand: Supermicro

Model: SSE-G3648BR

Form Factor: 1U Rackmount

Port Density: 48x 1Gbps RJ-45 Ethernet ports, 4x 10Gbps SFP+ uplink ports

Switching Capacity: 176 Gbps (Non-blocking)

Switching Chipset: Broadcom Helix4

Control Plane Processor: Intel Rangeley CPU

System Memory: 2GB DRAM

Storage: 8GB SSD

Airflow Direction: Reverse Airflow (Port-to-Power / Back-to-Front)

Software Environment: Pre-loaded with Open Network Install Environment (ONIE), Cumulus Linux Ready

Management Interface: 1x RJ-45 Dedicated Management Port, 1x RJ-45 Serial Console Port, 1x USB 2.0 Type-A Port

Power Architecture: Dual hot-swappable 200W redundant power supplies

Input Voltage: 100–127V / 200–240V AC, 50/60 Hz

Power Consumption: Less than 85.2 Watts

Dimensions: 17.1 x 11.2 x 1.73 inches (434 x 320 x 44 mm)

Weight: 18.03 lbs (8.18 kg with 2 PSUs)

Features:

  • Bare-metal open networking architecture with ONIE bootloader pre-installed
  • Reverse airflow cooling optimized for server hot/cold aisle compliance
  • Wire-speed Layer 3 IPv4/IPv6 routing and advanced Layer 2 switching capabilities
  • Hot-swappable, redundant power supply design for enterprise deployment
  • Includes mounting flanges/ears for standard 19-inch rack installation

(SSE-G3648BR)

Supermicro SSE-G3648BR 48-Port 1GbE 4-Port 10GbE SFP+ Switch

Brand: Supermicro

Model: SSE-G3648BR

Form Factor: 1U Rackmount

Port Density: 48x 1Gbps RJ-45 Ethernet ports, 4x 10Gbps SFP+ uplink ports

Switching Capacity: 176 Gbps (Non-blocking)

Switching Chipset: Broadcom Helix4

Control Plane Processor: Intel Rangeley CPU

System Memory: 2GB DRAM

Storage: 8GB SSD

Airflow Direction: Reverse Airflow (Port-to-Power / Back-to-Front)

Software Environment: Pre-loaded with Open Network Install Environment (ONIE), Cumulus Linux Ready

Management Interface: 1x RJ-45 Dedicated Management Port, 1x RJ-45 Serial Console Port, 1x USB 2.0 Type-A Port

Power Architecture: Dual hot-swappable 200W redundant power supplies

Input Voltage: 100–127V / 200–240V AC, 50/60 Hz

Power Consumption: Less than 85.2 Watts

Dimensions: 17.1 x 11.2 x 1.73 inches (434 x 320 x 44 mm)

Weight: 18.03 lbs (8.18 kg with 2 PSUs)

Features:

  • Bare-metal open networking architecture with ONIE bootloader pre-installed
  • Reverse airflow cooling optimized for server hot/cold aisle compliance
  • Wire-speed Layer 3 IPv4/IPv6 routing and advanced Layer 2 switching capabilities
  • Hot-swappable, redundant power supply design for enterprise deployment
  • Includes mounting flanges/ears for standard 19-inch rack installation

(SSE-G3648BR)

Quick Info

Model

Brand:
SuperMicro
Series:
SuperSwitch
Model Number:
SSE-G3648BR
Power Supply:
2x DPS-200PB-184 200W
Rail Kit:
Mounting Flanges Included (Outer rails optional)
Ears Included:
Yes
Feature Sets:
Layer 2/3 Advanced Enterprise Routing

Switch Specifications

Fixed Uplinks:
4 x 10Gbps SFP+
Total 10/100/1000 Ethernet Ports:
48 Ports
Available PoE Power:
N/A (Non-PoE)
Switching Capacity:
176 Gbps
Stacking Bandwidth:
N/A (Uses Standard SFP+ Uplinks for Stacking)
Total number of MAC addresses:
Information Not Specified by Manufacturer
Total number of IPv4 routes:
Information Not Specified by Manufacturer
FNF entries:
Not Supported
DRAM:
2 GB
Flash:
8GB
VLAN IDs:
4096
Total switched virtual interfaces (SVIs):
Information Not Specified by Manufacturer
Jumbo frame:
9216 Bytes
Total routed ports per stack:
N/A
Number of access points per switch/stack:
N/A
Number of wireless clients per switch/stack:
N/A
Total number of WLANs per switch:
N/A
Wireless bandwidth per switch:
N/A
Supported Aironet access point series:
N/A
Forwarding Rate:
130.95 Mpps

Dimensions & Weight

Length:
in.
Width:
in.
Height:
in.
Weight:
0.00 LBS.
